Overall Card Warpage Fixture

  • Intro
  • Features
  • Specifications
  • Ordering

Warpage-Fixture

Q-Card's overall card warpage fixture features precision, low friction stainless steel ball slide guide rails with defined gaps for accurate go/no-go testing of overall card warpage.

Q-Card offers two fixtures, one for embossed cards and one for unembossed cards. The gap for the unembossed fixture is calibrated to quickly identify an overall warpage of 1.5 mm. The embossed fixture gap is calibrated to identify an overall warpage of 2.5 mm.

The fixture is manufactured of aerospace-grade aluminum alloy with a hard anodized, scratch-resistant, durable finish to provide years of rigorous testing and trouble-free service. The fixture has splayed feet and aggressive no-slip rubber feet for extra stability when testing.

The overall card warpage fixture is designed to perform this test according to the following standards:

ISO/IEC


  • ISO 7810 Overall Card Warpage
  • ISO 7811-1 Embossing 5.1 Card Warpage
  • ISO 10373-1 Card Warpage

MasterCard CQM


  • Overall Card Warpage
  • Overall Card Warpage
  • Overall Card Warpage of Personalized XICC

Specifications

  • Weight: 2 pounds

Dimensions

Card-Warpage-Illustration

Ordering Details

Part #

Description

906740

Card Warpage Fixture for Unembossed Cards

906740-EMB

Card Warpage Fixture for Embossed Cards
